As-Built Floor Plans drawn on site. From a basic denoted floor plan, shower, room dimensions, and location to a complete floor plan with any level of information needed.

Basic floor plan: as-built walls and locations with room dimensions; shown as located. This can be as simple as one room to every room in the structure. I offer this service in Residential and commercial spaces.

From a basic floor plan we can go into further details like wall thickness and materials used, note items like insulations, drywall and materials layered in the walls make up, note window and door sizes, locations and structural members.

Also, I will layout electrical items such as lighting, receptacles and isolated circuits. To do this I power in the structure and must be able to turn off circuits and switches at will. This service is offered only for residential and commercial office spaces only.

As-Built drawings can be invasive or non-invasive.

Have prints on paper and want a live file? I draw prints in DWG and DXF. I draw with Chief Architect X15 which supports the above mentioned file formats. I can also turn any drawing I do into PDF or any picture file format (JPEG, BMP or PNG). Source files can be modified at any time to your liking.

Rendering available on any drawing we do is at an additional fee. We also do 3D Renders for building concepts, Zoning and planning board submission and design. We offer several levels of realism along with materials. Basic 3D or Ray traced.

We can turn any drawing or existing building into a 3D model for any purpose.

I started this company as a Millwork and cabinet installation business.
We offer drawing and design for Millwork and cabinetry, and we also install our designs if you are local to South jersey and the tri-state area.
